Know all about different types of concrete and grades used in construction!

The minimal strength that concrete should have after 28 days of construction with good quality control is known as concrete quality. The prefix M is placed in front of the required MPa strength and denotes concrete quality. For instance, a 20 MPa concrete grade is designated as M20, where M stands for Mix. These concrete kinds are transformed into various mixing ratios. For M20 concrete, for instance, the concrete: Sand: Coarse Aggregate mixing ratio would be 1:1.5:3.

Based on the demands of the structural design, the kind of concrete construction is chosen. Concrete mixes come in two varieties: nominal mix and design mix. The nominal concrete mix is typically utilized in modest-sized commercial and residential structures when there is little need for concrete. The nominal mix protects several frequent quality control issues that arise during the building of concrete structures. Concretes with mixing ratios determined by numerous laboratory experiments are known as design concretes. When using shotcrete, quality control must be maintained during the selection of materials, mixing, transportation, and placement of the concrete. When the large-scale concrete building is done, this concrete gives mixing ratios based on locally accessible ingredients and reduces construction costs. Shotcrete is therefore utilized in substantial concrete building projects.

Therefore, based on the structural requirements, a suitable concrete quality may be chosen. In minor construction, nominal mixes for concrete grades like M15, M20, and M25 are frequently employed. Large constructions need to be extremely strong, thus greater grades of concrete, such as M30 and higher, are used. These concrete mixing ratios depend on the mix design.

The concrete kinds M15, M20, M25, etc. are typical types. M15 is often utilized for routine cement concrete work. The concrete class must be at least M20 for constructions made of reinforced concrete. MPa (N/mm2)psi mixed grade concrete compressive strength

Concrete GradeMix RatioCompressive Strength
MPa (N/mm2)psi
Normal Grade of Concrete
M51: 5: 105 MPa725 psi
M7.51 : 4 : 87.5 MPa1087 psi
M101 : 3 : 610 MPa1450 psi
M151 : 2 : 415 MPa2175 psi
M201 : 1.5 : 320 MPa2900 psi
Standard Grade of Concrete
M251: 1: 225 MPa3625 psi
M30Design Mix30 MPa4350 psi
M35Design Mix35 MPa5075 psi
M40Design Mix40 MPa5800 psi
M45Design Mix45 MPa6525 psi
High Strength Concrete Grades
M50Design Mix50 MPa7250 psi
M55Design Mix55 MPa7975 psi
M60Design Mix60 MPa8700 psi
M65Design Mix65 MPa9425 psi
M70Design Mix70 MPa10150 psi
